Quick Details

  • Condition: New
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: VLIFT
  • Model Number: FD30
  • Type: Manual Pallet Truck
  • Power Souce: Diesel Engine
  • Rated Loading Capacity: 3000kg
  • Max. Lifting Height: 5660mm
  • Min. Lifting Height: 2005mm
  • Fork Length: 1070mm
  • Fork Width: 125mm
  • Overall Dimensions: 2705*1225*2190mm
  • Certification: CE/ISO9001
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product Name: 3 Tons Diesel Manual Forklift Trucks
  • Engine: China Engine
  • Loading Capacity: 3000kg
  • Mast: 2 stage mast forklift
  • Tire: Pneumatic
  • Weight: 4020kg
  • Load center: 500mm
  • Free lift: 120mm
  • Height to head guard: 2190mm
  • Gradeability at 1.6km/h: 20

Packaging & Delivery

Delivery Time 20 days
Product Description
 High Quality 3 Tons Diesel Manual Forklift Trucks
FD 30 3 Ton Hydraulic Diesel Forklift Technology Specification
Manufacturer    VLIFT
Model  Power shift T/M                      FD30
Load capacity   kg3000
Load center   mm500
Power unit    Diesel
Operator type    Driver/seat
Tire type    Pneumatic
Wheel  Front/rear 2/2
Max. lifting height    mm3000
Free lift   mm160
Fork size                      L*W*Tmm1070*125*45
Tilt range   Mast forward/backward            deg6/12
Overall length(without fork)                   mm2705
Total width   mm1225
Mast height (fork lowering)                  mm2005
Overall height fork raised                     With backrest                                     mm5660
Height to head guard                            mm2190
Turning raduis(outside)                            mm2450
Front face of fork to front axle                  mm480
Min. right angle stacking aisle               without load length&clearence                    mm2925
Speed  Max Travelling         full/no load           km/h18/19.5
Lifting                        full/no load                mm/s450/500
Lowering                    full/no load                          mm/s450/450
Max.drawbar pull                                    Power shift T/M       full/no load                                      kg1500/1000
Gradeability at 1.6km/h                            Power shift T/M       full/no load                                      %18/20
Truck weight  kg4020
Weight  distribution                             Full  load              front/rear            kg6490/890
No  load               front/rear           kg1670/2700
Tires  Number front/rear2/2
Model front axle  28x9-15-12PR
rear axle 6.50-10-10PR
Wheelbase   mm1700
Tread  Front/rearmm1000/970
Ground clearence    At lowest point(mast)                        mm120
Frame mm135
Brake  Service  brake Hydraulic-foot pedal
Parking brake  Mechanical-hand lever
Battery    Voltage/capacityV/AH12/80
Engine                                          Model  Chinese Quanchai 4C2
Rated power kw/rpm36.8/2500
Rated torque N.m/rpm156/1700-1900
Number of cylinders  4
Placement L2.369
Fuel tank capacityL70
TransmissionSpeed forward/backwardPower shift1-1 power shift
Operating pressure                              Hydraulic system pressure               kg/cm²180
Certifications



FAQ

1. How long it will take to deliver the product after I pay for it?



Above price valid time is 25 days.





2. What is the payment term?



Our Payment: T/T, L/C, etc.





3. How long is the warranty period any forklift, pallet truck, stacker, scissor lift etc?



Our equipment quality warranty is 1 year or 2000 hours which comes first.





4. What kinds of engine do you have and any gurantee?



Chinese engine, Japanese ISUZU, Mitsubishi, YANMAR, Nissan K21, Nissan K25 engine as per your request. Absolutely high quality.





5. How many colors of forklift you can supply?



Sliver, Orange, Yellow, Red. As Per Your Request.



6. What is the forklift standard configuration and spare parts?

Wide vision mast,standard fork,standard seat,direction switch,backrest,reversing lights,reversing buzzer,back-up mirror,light switch,light armor rack,klaxon,two pieces of multi-way valve,electric control,rear combination lamp,overhead guard,rain cover,urable tyre,lasso-parking brake,lifting and tilt joystick,rate-limiting valve of lifting,draebar pin,lighting,adjustable steering wheel,lilt line self-lock valve,full hydraulic power steering,handle,tool box,combination instrument,hydraulic return filter,hydraulic oil suction filter,hydraulic vernier,switch,brake,turning indicator.

Our Factory Show

Shanghai Vlift Equipment Co., Ltd. is one of the leading suppliers of diesel forklifts, gasoline/LPG forklifts, electric forklift, electric pallet trucks, electric stackers, manual pallet trucks, manual stackers, oil drum carriers, container ramps, work platforms, and lift tables.



Vlift aims at provide you high quality, high performance material handling equipment.


Everywhere in the world you can see products made in China, and Vlift has the responsibility to offer you the satisfactory equipments at good price.
